Solar Panel

150W SOLAR PANEL
Package Includes：
1X A GRADE POLYCRYSTAL SOLAR PANEL 150W
1X EPEVER MPPT 20A CONTROLLER
1X 7 PIECES ABS CARAVAN SOLAR PANEL MOUNTING KIT
2 x MC4 cables
150w Mono-Crystalline Photo-voltaic for boat caravan home
The low reflective properties of the 3.2mm safety/tempered glass front allows for maximum light absorption, while the low-iron content of the glass gives it more transparency than other types of glass for maximum solar production. A corrosion-resistant anodized aluminum frame surrounding the solar panel adds strength and allows for easy mounting.
The junction box attached to the back of the solar panel has a weather tight seal with an Ingress Protection rating of 65, a built-in bypass diode in the junction box provided added protection to panels connected in series during partial shading on an array. This solar panel is also supplied with 900mm of cable for each positive/negative with the standard MC4 solar panel connectors crimped onto each cable.
:
Maximum Power (Pmax): 150W
Maximum Power Voltage (VMP): 18.0V
Maximum Power Current (IMP): 8.33A
Open Circuit Voltage (VOC): 21.60V
Short Circuit Current (ISC): 9.17A
Weight: 9.85KG
Size: 1480 680 35mm
Power Tolerance: /-3%
Maximum System Voltage: DC1000V
Lightweight designed with rigid anodised aluminium alloy frame and toughened glass
made of High-Efficiency PV Cells
Appearance Consistency
Frame:
Conventional frame
Silver frame
We do also Stock
50W
60W
100W
150W
200W
260W
Please check the availability with us.
Applications:
can be used for Power Stations, Generation Systems, Street Lights, garden Lights and many other application.
