Ecoflow Power Hub, Smart Distribution Panel & Power Kit Console | Power Kits

Stay up to date

Update firmware to keep your system protected and improve functionality.
Customize
Adjust 12/24 DC output voltage, AC input frequency and current, charging and discharging levels. Monitor
Monitor DC output and real-time battery charging data, including charging time. Stay up to date
Update firmware to keep your system protected and improve functionality.
Cable Pack

Each Power Kit includes a pack of five space-saving cables that reach lengths of 15ft and 20ft, allowing you to conveniently place your batteries and power sources wherever you want. The package consists of cables for AC Charging, Alternator Charging, and Solar Charging, as well as Main Out Cables for AC and DC. Each directly plugs into the Power Hub without the need for additional accessories.

Specifications: Power Hub

Net Weight (kg): 14
Dimension (cm): 30 x 48 x 14 cm (Height x Width x Depth)
Wi-Fi: ✓
Bluetooth: ✓
Mobile App: ✓
AC Main Output/Frequency: Pure Sine Wave, 3,600W (Surge 6,000W), 230V, 50Hz/60Hz
DC Main Output: 13.6V/70A 1000W Max: 26.4V/60A. 1500W Max
AC Main Input: X-Stream Fast Charging 3000W Max, 16A Max
AC Main Input Voltage/Frequency: 220-240V, 50Hz/60Hz
Solar Charging Input: 15-60V 30A, 1600W Max
Alternator Charging Input: 13V-60V, 60A, 1000W Max
AC Charging: 220-240V,15A,3000W Max
Operating Temperature: -25℃-60℃
Discharge Temperature: -25℃-60℃
Charge Temperature: -25℃-60℃
Storage Temperature: -25℃-60℃
Power Kit Console

Touch Screen (Diagonal Measurement): 7 Inch (6x3.4in) (Width x Height)
Power Supply Voltage: 12 VDC
Operating Temperature (C): -20℃-60℃
Dimension (cm): 11.3 x 20.5 x 2.2 cm (Height x Width x Depth)
Net Weight (kg): 0.45
AC/DC Smart Distribution Panel

AC Main Input: 16A Max. 230V, 3600W
DC Main Input: 70A Max
AC Output: 6 AC Positions, 10A Max Each
DC Output: 12 Fused DC Positions (6 Positions Controllable via Power Kit Console & App)
Operating Temperature (C): -25℃-60℃
Net Weight (kg): 2.6
Protection Level: IP21
