Standard Single Acting Spring Return Cylinders

Capacity
(Ton)

Stroke
(mm)

Min. Height
(mm)

Outside Diameter
(mm)

Effective Area
(cm 2 )

Oil Capacity
(cm 2 )

5

16 - 232

41 - 323

38 - 40

6.5

10 - 151

10

26 - 356

89 - 450

57

14.5

38 - 516

15

51 - 203

149 - 322

69

20.3

104 - 411

25

26 - 362

139 - 476

85

33.2

86 - 1202

50

159

282

127

71.2

1131

- Capacity from 5 to 50 T, stroke up to 159 mm.
- Industrial general purpose cylinders.
- Strong spring for quick retraction, can be used in all positions.
- Collar threads, piston end threads and base holes, for accessory mounting.
- Heavy cylinders have carrying handles or eye bolts as standard.
- Accessories.
- Optional tilting saddles. ---
