HEATPORT H2S 2.5kW Diesel Air Heater 24V (DC) with Marine Pro Kit

Fixed installation air heating unit.

- Overall energy delivery: 1kW - 2.7kW
- Heat output: 0.8kW - 2.5kW
- Extra wide heat output range
- Intake duct: Ø60mm
- Outlet duct: Ø60mm
- Ultra low noise level
- Extra low el. consumption
- Fuel saving thermostat (cycling)
- Enhanced temperature stability
- Fixed power mode
- Water-resistant electronics
- Dual overheating sensor
- Brushless motor
- External ambient temp. sensor
- Bluetooth / iOS App (BETA)

Kit Includes:

1 x Ambient Temperature Sensor 10k NTC

1 x Fuel Pump 65ml Type C with Dumper

1 x Fuel Pump Holder

1 x Fuel Pump Suspension Strip

1 x Fuel Filter Horizontal with Drain

1 x 1M Length of Fuel Hose Rigid - Nylon Blue ID-Ø 2mm / OD-Ø 5mm

1 x 4M Length of Fuel Hose Rigid - Nylon White ID-Ø 2mm / OD-Ø 4mm

1 x 300mm Length of Fuel Hose Flexible - Reinforced Rubber Black ID-Ø 4mm / OD-Ø 10.5mm

2 x Fuel Hose Sleeve - Reinforced Rubber Black ID-Ø 5mm / OD-Ø 10.8mm

4 x Fuel Hose Sleeve - Reinforced Rubber Black ID-Ø 4mm / OD-Ø 10mm

1 x Suction Pipe with Nut

3 x Air Vent / Inlet & Outlet Ø 60mm Type A

1 x T-Junction Ø 60mm Type A

1 x 2M Length of Duct Hose Black Ø 60mm

1 x Air Intake Foam Silencer with Cap Ø 25mm

1 x Air Intake Hose Black Ø 25mm

1 x 1M Long Flexible Exhaust Pipe Ø 24mm

1 x Exhaust Silencer / Muffler - Offset Marine Ø 24mm MK2

1 x 1M Length of Fiberglass lagging / insulation sleeve for exhaust pipe

1 x Exhaust Through Hull / Skin Fitting Ø 24mm Type H

1 x Gasket Maker & Sealant RTV

1 x Muffler Sealant 170gm J-B Weld

1 x Bottom plate MK2 Zinc Plated

1 x Bottom Plate L-Shaped Bracket (WALL)

1 x Mounting Bracket SS for Silencer

8 x Hose Clamp Ø 60mm (50-70mm)

5 x Hose Clamp 27mm (26-28mm) Heavy Duty

2 x Hose Clamp Ø 24/25mm (19-29mm)

2 x Hose Clamp Ø 10mm (9-11mm)

8 x Hose Clamp Ø 9mm (8-10mm)

1 x Mounting Saddle for Air Intake Silencer Ø 55mm

2 x Hose / Pipe Saddle

1 x Mounting Saddle for Air Intake Hose Ø 27mm

2 x Mounting Saddle Plastic Ø 60mm

12 x Cable Ties

1 x 15cm Straight Bracket

1 x Set of Screws for Bottom Plate

1 x Installation Manual
