HEATPORT H2S 2.5kW Diesel Air Heater 12V (DC) with RV Kit

Fixed installation air heating unit.

- Overall energy delivery: 1kW - 2.7kW
- Heat output: 0.8kW - 2.5kW
- Extra wide heat output range
- Intake duct: Ø60mm
- Outlet duct: Ø60mm
- Ultra low noise level
- Extra low el. consumption
- Fuel saving thermostat (cycling)
- Enhanced temperature stability
- Fixed power mode
- Water-resistant electronics
- Dual overheating sensor
- Brushless motor
- External ambient temp. sensor
- Bluetooth / iOS App (BETA)

Kit Includes:

1 x H2S Heater Assembly with associated wiring and controller

1 x Fuel Pump 65ml Type C with Dumper

1x Fuel Pump Holder

1 x Fuel FIlter Vertical

1 x 4M Length of Fuel Hose Rigid - Nylon White ID-Ø 2mm / OD-Ø 4mm

6 x Fuel Hose Sleeve Joiners - Reinforced Rubber Black ID-Ø 4mm / OD-Ø 10mm

1 x Suction Pipe with Nut

1 x Air Vent / Inlet & Outlet Ø 60mm Type A

1 x 1M Length of Duct Hose Brown Ø 60mm

1 x 500mm Long Air Intake Hose with Cap Ø 25mm - 0.5m

1 x Air Intake Foam Silencer with Cap Ø 25mm

1 x 600mmL Flexible Exhaust Pipe with Cap Ø 24mm

1 x Exhaust Silencer / Muffler Ø 24mm Type A

1 x Gasket Maker & Sealant RTV

1 x Bottom plate MK2 Zinc Plated

1 x Mounting Bracket SS for Silencer

2 x Hose Clamp Ø 60mm (50-70mm)

3 x Hose Clamp 27mm (26-28mm) Heavy Duty

2 x Hose Clamp Ø 24/25mm (19-29mm)

12 x Hose Clamp Ø 10mm (9-11mm)

1 x Hose / Pipe Saddle

1 x Mounting Saddle for Air Intake Hose Ø 27mm

4 x Cable Ties

1 x 15cm Straight Bracket

1 x Set of Screws for Bottom Plate

1 x Installation Manual
