HEATPORT H4S 4.5kW Diesel Air Heater 24V (DC) with RV Kit
- Overall energy delivery: 1.2kW - 5kW
- Heat output: 1kW - 4.6kW
- Extra wide heat output range
- Intake duct: Ø75mm
- Outlet duct: Ø90mm (4xØ43mm/Ø75mm)
- Ultra low noise level
- Extra low el. consumption
- Fuel saving thermostat (cycling)
- Enhanced temperature stability
- Fixed power mode
- Water-resistant electronics
- Dual overheating sensor
- Brushless motor
- External ambient temp. sensor
- Bluetooth / iOS App (BETA)
Kit Includes:
1 x Ambient Temperature Sensor 10k NTC
1 x Fuel Pump 65ml Type C with Dumper
1 x Fuel Pump Holder
1 x Fuel Filter Vertical
1 x 4M Length of Fuel Hose Rigid - Nylon White ID-Ø 2mm / OD-Ø 4mm
6 x Fuel Hose Sleeve Joiners - Reinforced Rubber Black ID-Ø 4mm / OD-Ø 10mm
1 x Suction Pipe with Nut
1 x Air Vent / Inlet & Outlet Ø 90mm Type C
1 x 1M Length of Duct Hose Ø 90mm
1 x Air Intake Hose with Cap Ø 25mm - 0.5m
1 x Air Intake Foam Silencer with Cap Ø 25mm
1 x 600mm Long Flexible Exhaust Pipe with Cap Ø 24mm
1 x Exhaust Silencer / Muffler Ø 24mm Type A
1 x Gasket Maker & Sealant RTV
1 x Bottom plate MK2 Zinc Plated
1 x Mounting Bracket SS for Silencer
2 x Hose Clamp Ø 90mm (80-100mm)
3 x Hose Clamp 27mm (26-28mm) Heavy Duty
2 x Hose Clamp Ø 24/25mm (19-29mm)
12 x Hose Clamp Ø 10mm (9-11mm)
1 x Hose / Pipe Saddle
1 x Mounting Saddle for Air Intake Hose Ø 27mm
4 x Cable Ties
1 x 15cm Straight Bracket
1 x Set of Screws for Bottom Plate
1 x Installation Manual
