Astra Walker Transformer

A69.58.V2.H.TFR

For use with the Astra Walker heated towel rails horizontal and vertical.

- Lamp wattage 35…105 W
- Maximum output power 105 W
- Line current 0.45 A 1)
- Nominal voltage 220…240
- Power factor 0.95 2)
- Operating frequency 40 kHz 3)
- Nominal output voltage 11.9 / 12.0 V 4)
- Input voltage AC 198…264 V
- Mains frequency 50…60 Hz
- System wattage 111.00 W
- Efficiency in full-load 94 %
- Input voltage range 220…240 V
- Galvanic isolation primary/secondary 4.00 kV5
- Inrush current 0.5 A
- NOTE : 1 Transformer can run up to 5 horizontal or 3 vertical rails in a single location
