Product Type DIN-Rail Power SupplyLength (mm) 112Width (mm) 67Height (mm) 35Housing Color WhiteHousing Material PCMounting DIN-RailWeight (g) 125Input Domain ACInput Voltage 100 ~ 240V ACOutput Voltage 15V DCLED Output Current (max per output, mA) 200Output Current Max. (A) 0.2 Output Power Range (W) 0~3 Power Supply Internal Inrush Current 10A @ 230VAC

Input Voltage: 100-240VAC 50/60Hz Input Current: 115VAC/≤0.09A, 230VAC/≤0.05A Out Current: 200mA Working Voltage: 15V working temp. -30℃～55℃ Dimension L135×W30×H20(mm) Package Size L140×W34×H23mm Weight (G.W) 75g

This DIN Rail Dali LED controller is suitable for dimming LED strips using a Dali signal. The controller has two output signals: a 10A and a 0-10V signal. This LED controller can be easily mounted on a DIN Rail.

- Latest DALI standard protocol IEC62386.- Support switch and dimming function.- DALI bus supply power.- The DIP switch can set address.- Support scene, group, unicast, broadcast mode.

- Latest DALI standard protocol IEC62386.- Support switch and dimming function.- DALI bus supply power.- The DIP switch can set address.- Support scene, group, unicast, broadcast mode.

- Latest DALI standard protocol IEC62386.- Support switch and dimming function.- DALI bus supply power.- The DIP switch can set address.- Support scene, group, unicast, broadcast mode.

The dimmer module requires a low voltage input and a DALI signal from a suitable DALI Controller. The input and output is via screw terminals on the sides of the unit.The DALI dimmer module operates on a low voltage 12~24V DC circuit, providing a PWM output for powering and dimming LED's. A 0-10V signal output is also provided.

Dimming interface: DALI, Push Dim.PWM digital dimming, standard DALI logarithmic dimming curve.Dimming range: 0~100%, LED start at 0.1% possible.4CH isolated control output, Max. current output: 20A.Full protective plastic housing.DALI bus standard: IEC62386.Suitable for indoor environments.

Input signal DALI digital dimming signal Input voltage DC12V～DC24V Output12A ×1CH 0-10V ×1CH Max output power 144W(12V) 288W(24V)Dimming Range 0.1～100% working temperature -30℃～55℃ Dimension L175×W44×H30(mm) Package Size L178×W48×H33(mm)
